Long Life Time Ultrasonic Transducer Welding For Creat Cavitation Inside Tube

Name: Long Life Time Ultrasonic Transducer Welding For Creat Cavitation Inside Tube
Brand: QRsonic
Price: 1 USD

Buy cheap Long Life Time Ultrasonic Transducer Welding For Creat Cavitation Inside Tube product

Brand Name : QRsonic

Model Number : QR-6015-4BZ

Certification : CE

Place of Origin : China

MOQ : 1 pcs

Price : Negotation

Payment Terms : T/T, Western Union

Supply Ability : 2000pcs per month

Delivery Time : 3 workdays

Packaging Details : Packed in carton

Products Name : Ultrasonic Welding Transducer

Frequency : 15 khz

Output power : 2600 watt

Joint bolt : M20*1.5

Ceramic disc Diameter : 60mm

Qty of ceramic discs : 4pcs

Capacitance : 9-13.5nf

Amplitude : 10 um

Contact Now

15Khz 2600watts Ultrasonic Transducer for A New Application to Creat Cavitation Inside Tube

Description:

The transducer converts high-frequency electrical energy into high-frequency mechanical vibrations. And it contains several piezoelectric ceramic discs sandwiched under pressure between two metal blocks. Between each disc is a thin metal plate, which forms the electrode. When a sinusoidal electrical signal is fed to the transducer via the electrodes, the discs expand and contract, producing axial vibrations.

The transducer consists of a housing, a matching layer, a piezoceramic disk transducer, a backing, an extraction cable, and a Cymbal array receiver. The piezoelectric ceramic disk transducer is made of PZT-5 piezoelectric material with polarization direction polarization. The Cymbal array receiver consists of 8 to 16 Cymbal transducers, two metal rings and rubber gaskets. The working distance of the invention is greater than 35 m, the frequency bandwidth reaches 10 kHz, and the long-distance target moving at high speed can be detected.

Specifications:

Model	QR-6015-4BZ
Frequency	15 khz
Output power	2600 watt
Joint bolt	M20*1.5
Ceramic disc Diameter	60mm
Qty of ceramic discs	4pcs
Capacitance	9-13.5nf
Amplitude	10 um
Application	Plastic welding machine

The columnar type NTK TYPE
Item No.	Connect screw	Ceramic dia (mm)	Qty of Ceramic (pc)	Frequency (khz)	Capacitance			power (W)
Item No.	Connect screw	Ceramic dia (mm)	Qty of Ceramic (pc)	Frequency (khz)	Yellow	Grey	Black	power (W)
7015-4BZ	M20 X 1.5	70	4	15	12500-14000		17000-19000	2600
6015-4BZ	M20 X 1.5	60	4	15	8000-10000	10000-12000	12500-13500	2200
6015-6BZ	M20 X 1.5	60	6	15	14000-16000		19500-21000	2600
5015-4BZ	M18 X 1.5	50	4	15	12000-13000	13000-14300	15000-17000	1500
4015-4BZ	M16 X 1	40	4	15	10000-11000	10500-11500		700
5520-4BZ	M18 X 1	55	4	20	10000-11000	10500-11500	14300-20000	2000
5020-6BZ	M18 X 1.5	50	6	20	18500-20000		22500-25000	2000
5020-4BZ	M18 X 1.5	50	4	20	11000-13000	13000-15000	15000-17000	1500
5020-2BZ	M18 X 1.5	50	2	20	6000-6500	6500-7000	8000-9000	800
5020-4CZ	M18 X 1.5	50	4	20	11000-12000	13000-14000	14500-16000	1500
5020-4HZ	M18 X 1.5	50	4	20			11000-12000	1500
5020-4BL	M18 X 1.5	50	4	20	11000-12500			1500
4020-4BZ	1/2-20UNF	40	4	20	9000-10000	9500-11000		900
4020-2BZ	1/2-20UNF	40	2	20		4800-5500		500
3820-4BZ	1/2-20UNF	38	4	20	6500-7500			800
The columnar type NTK TYPE
Item No.	Connect screw	Ceramic dia (mm)	Qty of Ceramic (pc)	Frequency (khz)	Capacitance			power (W)
Item No.	Connect screw	Ceramic dia (mm)	Qty of Ceramic (pc)	Frequency (khz)	Yellow	Grey	Black	power (W)
5025-2BZ	M12 X 1	50	2	25	5000-5600		7000-8000	500
3828-2BZ	1/2-20UNF	38	2	28	3800-4300			500
3828-4BZ	1/2-20UNF	38	4	28	7600-8500		10500-12000	800
3028-2BZ	3/8-24UNF	30	2	28	2700-3100	3400-3800		400
3028-4BZ	M10*1	30	4	28		6000-7000		700
2528-4FZ	M8 X 1	25	4	28	3900-4300			400
2528-2FZ	M8 X 1	25	2	28	1950-2200	2200-2500		300
3030-4BZ	M10	30	4	30		6200-6900		700
3035-2FZ	3/8-24UNF	30	2	35	2700-3100			500
3035-4BZ	M10 X 1	30	4	35	5000-6200			800
2535-2FZ	M8 X 1	25	2	35	1900-2200			400
2540-2BZ	3/8-24UNF	25	2	40		2000-2300		500
3040-4BZ	M10	30	4	40	5500-6200			1000
3050-4BZ	M8	30	4	50	5500-6200			600
1560-2BZ	M6 X 0.75	15	2	60			700-800	100

15Khz 2600watts Ultrasonic Transducer for A New Application to Creat Cavitation Inside Tube

Long Life Time Ultrasonic Transducer Welding For Creat Cavitation Inside Tube
